EU Version Oneplus Open

Dimensions

    When open

•     Height: 153.4 mm
      Width: 143.1 mm
      Thickness: 5.8 mm (Emerald Dusk version)
      Thickness: 11.9 mm (Voyager Black version)
      Thickness: 5.9 mm (Crimson Shadow version)

    When closed

• Height: 153.4 mm
  Width: 73.3 mm
  Thickness: 11.7 mm (Emerald Dusk version)
  Thickness: 11.9 mm (Voyager Black version)
  Thickness: 11.9 mm (Crimson Shadow version)

    Weight

• Voyager Black: 239g
  Emerald Dusk: 245g
  Crimson Shadow: 239g

Display

    Main display (primary display)

• Size: 7.82" diagonally measured from corner to corner
  Resolution: 2440*2268 (2K), 426 ppi
  Aspect ratio: 1.0758:1
  Screen-to-body ratio: 89.6%
  Refresh rate: 1–120 Hz dynamic
  Panel type: Flexi-fluid AMOLED with LTPO 3.0
  Typical (HBM) / Peak brightness: 1400 / 2800 nits
  Supports sRGB, DCI-P3, 10-bit color depth
  97% NTSC / 100% DCI-P3
  Touch response: Up to 240 Hz
  Pulse width modulation: 1440 Hz
  Protective material: Ultra Thin Glass
  Certification: TÜV Rheinland Intelligent Eye Care

    Cover screen (secondary display)

• Size: 6.31" measured diagonally from corner to corner
  Resolution: 2484*1116 (2K), 431 ppi
  Aspect ratio: 20:09
  Screen-to-body ratio: 91.8%
  Refresh rate: 10–120 Hz dynamic
  Panel type: Super Fluid AMOLED with LTPO 3.0
  Typical (HBM) / Peak brightness: 1400 / 2800 nits
  Supports sRGB, DCI-P3, 10-bit color depth
  97% NTSC / 100% DCI-P3
  Touch response: Up to 240 Hz Protective material: Ceramic Guard
  Certification: TÜV Rheinland Intelligent Eye Care

    Characteristics

• Natural tone display
  Eye comfort
  Image sharpener
  Video color enhancer
  Screen color mode
  Color personalization
  Color vision enhancement
  Auto brightness
  Manual brightness
  Screen color temperature
  Bright HDR video mode
  Night mode
  Multi-level color calibration

Performance

• Operating System: OxygenOS 13.2 based on Android™ 13 (Emerald Dusk/Voyager Black variant)
  Operating System: OxygenOS 14.0 based on Android™ 14 (Crimson Shadow variant)
  CPU: Qualcomm® Snapdragon™ 8 Gen 2 Mobile Platform
  5G Chipset: X70
  GPU: Adreno™ 740
  RAM: 16GB LPDDR5X with RAM-Vita
  RAM Expansion: 4/8/12GB
  Storage: 512GB/1TB UFS 4.0
  Battery: 4,805 mAh (Dual-cell, 3295+1510 mAh, non-removable)
  67W SUPERVOOC Charging
  Haptics: X-axis motor
  Certification: TÜV SÜD 48-month Fluency Rating A

camera

    Main camera

• Sensor: Sony LYT-T808 “Pixel Stacked” CMOS
  Sensor size: 1/1.43"
  Megapixels: 48
  Pixel size: 1.12 µm
  Number of lenses: 7P
  Optical image stabilization: Yes
  Electronic image stabilization: Yes
  Focal length: 24 mm equivalent (1X), 47 mm equivalent (2X)
  Aperture: ƒ/1.7
  Field of view: 85°
  Autofocus: Yes

    Telephoto

• Sensor: OmniVision OV64B with 3X optical zoom, 6X in-sensor zoom
  Sensor size: 1/2"
  Megapixels: 64
  Pixel size: 0.7 µm
  Number of lenses: 4P
  Optical image stabilization: Yes
  Electronic image stabilization: Yes
  Focal length: 70 mm equivalent (3X), 145 mm equivalent (6X)
  Aperture: ƒ/2.6
  Field of view: 33.4°
  Autofocus: Yes
  Ultra Res zoom (digital): Up to 120X

    Ultra wide angle

• Sensor: Sony IMX581
  Sensor size: 1/2"
  Megapixels: 48
  Pixel size: 0.8 µm
  Number of lenses: 6P
  Electronic image stabilization: Yes
  Focal length: 14 mm equivalent
  Aperture: ƒ/2.2
  Field of view: 114°
  Autofocus: Yes
  Macro: 3.5 cm

    Other sensor(s) ：   Multi-channel color temperature sensor

    flash ：   LED

    Autofocus：Multi-autofocus for the main camera (omnidirectional all-pixel PDAF+CAF)

    video

• 4K video at 30/60 fps
  1080p video at 30/60 fps
  720p video at 30/60 fps
  Dolby Vision® HDR at 4K, 30 fps; 1080p, 30 fps
  Ultra Steady video at 1080p, 60 fps
  Pro mode at 4K, 30 fps
  Slow motion video at 1080p, 240/480 fps; 720p, 240/480 fps
  Time lapse at 4K, 30 fps
  Digital zoom: Up to 20X
  Dual-view video at 1080p, 30 fps
  Video editor

    Characteristics：Hasselblad Mobile Camera, Night Scene, Dolby Vision®, Intelligent Scene Detection, Portrait Mode, Pro Mode, Panorama, Tilt-Shift Mode, Long Exposure, Dual View Video,                                         Retouch, Movie Mode, XPan Mode, Focus Peaking, Raw File, Raw Plus File, Filters, Super Steady, Video Night Scene, Video HDR, Focus Lock, Time Lapse, Google Lens

     Main front camera (on the main/primary display)：

• Megapixels: 20
  Sensor size: 1/4"
  Number of lenses: 4P
  Pixel size: 0.7 µm
  Electronic image stabilization: Yes
  Focal length: 20 mm equivalent
  Autofocus: Fixed focus
  Aperture: ƒ/2.2
  Field of view: 91°

    Front camera (on the secondary/cover screen)

• Megapixels: 32
  Sensor size: 1/3.14"
  Number of lenses: 5P
  Pixel size: 0.7 µm
  Electronic image stabilization: Yes
  Focal length: 22 mm equivalent
  Autofocus: Fixed focus
  Aperture: ƒ/2.4
  Field of view: 88.5°

    Video (front cameras)

• 4K video at 30 fps
  1080p video at 30 fps (default)
  720p video at 30 fps

    Characteristics：Face unlock, Night selfie, Selfie HDR, Time-lapse, Dual-view video, Screen flash

Connectivity

                                    eSIM

    LTE/LTE-A：4×4 MIMO, supports up to DL Cat 20/UL Cat 13 (1.2Gbps /200Mbps), depending on vendor support

    band：MIMO: LTE: B1, 2, 3, 4, 7, 25, 28, 38, 40 (3x), 41, 48, 71;
                  WCDMA: B1, 2, 4, 5, 6, 8, 19
                  LTE-FDD: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28/30/32/66/71
                  LTE-TD: B38/39/40/41/46/48
                  5G NR: n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n30, n38, n40, n41, n66, n71, n75, n77, n78
                  GSM: 850/900/1800/1900
                  (No CDMA)

    Wi-Fi：2×2 MIMO, support 2.4G/5G/5.8G, WLAN 6E, WLAN 7, support WLAN 802.11 a/b/g/n/ac/ac Wave 2/ax/be, 8 spatial stream sound MU-MIMO

    Bluetooth：Bluetooth 5.3
                           Codex supported: aptX HD, aptX, LDAC, LHDC, AAC, SBC

    NFC：NFC-enabled

    Location：GPS (L1+L5 dual band), GLONASS, Galileo (E1+E5a dual band), Beidou, A-GPS, QZSS

Sensors

• Side-mounted Fingerprint Sensor
  Accelerometer
  M-sensor Electronic Compass
  Gyroscope
  Ambient Light Sensor
  Proximity Sensor
  Sensor Core
  Flick-detect Sensor
  Infrared Sensor

Connections

• USB 3.1
  Type-C
  Support standard Type-C earphones
  Dual nano-SIM slot

Keys

• "Reality" Speakers
  Noise cancellation support
  Dolby Atmos®

Audio

• "Reality" Speakers
  Noise cancellation support
  Dolby Atmos®

multimedia

    Supported audio formats：Playback: MP3, AAC, AAC+, WMA, AMR-NB, AMR-WB, WAV, FLAC, APE, OGG, MID, M4A, IMY, AC3, EAC3, EAC3-JOC, AC4
                                                        Recording: Wav, AAC. AMR

    Dolby Vision®：HDR10/HDR10+

    Supported video formats：Playback: MKV, MOV, MP4, H.265 (HEVC), AVI, WMV, TS, 3GP, FLV, WEBM
                                                        Recording: MP4

    Supported image formats：Playback: JPEG, PNG, BMP, GIF, WEB, HEIF, HEIC, DNG
                                                         Output: HEIF, JPEG, DNG (RAW)

Security chip       * only for Crimson Shadow

• Model: GSEA0
  Processor: ARM SC300 Core / Frequency: 96 MHz
  Certification: SOGIS CC EAL5+
